Product Details:
|
| Bucket Capacity: | 0.3-1.2CBM | Application: | Extending The Vertical Depth |
|---|---|---|---|
| Max Digging Depth: | 16-27m | Colour: | Customized |
| Highlight: | telescopic boom excavator clamshell bucket,soil taking excavator clamshell bucket,telescopic boom excavator clamshell |
||
Products Description
Technical Specification of Clamshell Telescopic Arm
| Technical Specification of KM Telescopic Excavator Boom | |||
| Type | KM150 | KM220 | KM260 |
| System | Hydraulic cylinder&Wire rope | Hydraulic cylinder &Wire rope | Hydraulic cylinder&Wire rope |
| Weight | 3.6t | 4.6t | 5.6t |
| Bucket Capacity | 0.3m³ | 0.6m³ | 1.2m³ |
| Max. Digging Depth | 15200mm | 22490mm | 27180mm |
| Max. Digging Radius(Reach Max. Digging Depth) | 4670mm | 5845mm | 6400mm |
| Max.Vertical Digging Radius | 6430mm | 7445mm | 8530mm |
| Max. Digging Depth(Reach Max. Vertical Digging Radius) | 11825mm | 19920mm | 22370mm |
| Max. Operating radius | 7950mm | 9835mm | 11250mm |
| Max. Hoisting Height | 2870mm | 4465mm | 5770mm |
| Min. Operating Radius | 3980mm | 4485mm | 5460mm |
| Max. Operating Height | 9475mm | 13580mm | 16675mm |
| Overall Transport Length | 6908mm | 10685mm | 12390mm |
| Weight of Bucket | 520Kg | 990Kg | 1600Kg |
| Recommended excavator capacity | ≥15ton | ≥23ton | ≥36ton |
