KR300C Hydraulic Piling CAT Chassis

Large Image : KR300C Hydraulic Piling CAT Chassis

Product Details:

Place of Origin:	China
Brand Name:	TYSIM
Certification:	CE/ISO900A
Model Number:	KR300C

Payment & Shipping Terms:

Minimum Order Quantity:	1 set.
Price:	230000
Packaging Details:	Nude packing and overall transport by sea with roll-on-roll-off ship; One Flat rack container
Delivery Time:	1-3month
Payment Terms:	L/C, T/T, D/P

Contact Now

KR300C Hydraulic Piling CAT Chassis

Description

Product Name:	Piling Rig Machine	Max Drilling Diameter:	1000
Max Torque:	300	Max Drilling Depth:	23(17+6)
Main Winch Force:	320	Crownd Force:	220
Stroke:	17	Base Engine:	CAT C-9
Highlight:	Diesel Engine Piling Rig , 320KN Drilling Rig Machine , KR300C Piling Rig Machine

Drilling Rig KR300C Diesel Engine Piling Equipment

The original made in USA powerful Cummins engine is selected to integrate with the core technology of TYSIM in electronic

control system and hydraulic system to maximize its working performance.

The whole series of Tysim products have passed GB certification and EU EN16228 standard certification, better dynamic and

static stability design to ensure construction safety;

New and upgraded Caterpillar chassis with high quality to ensure the best performance of the whole machine;

Add pressure and power head torque perfectly match,

more efficient rock entry;

Technical specification of KR300C rotary drilling rig
Torque	300kN.m
Max. diameter	2200 mm
Max. drilling depth	80/54 m
Speed of rotation	7~23 rpm
Max. crowd pressure	260 kN
Max. crowd pull	260 kN
Main winch line pull	340 kN
Main winch line speed	72 m/min
Auxiliary winch line pull	90 kN
Auxiliary winch line speed	70 m/min
Stroke(crowd system)	6000 mm
Mast inclination(lateral)	±5°
Mast inclination(forward)	5°
Max. operating pressure	34.3 MPa
Pilot pressure	3.9MPa
Travel speed	1.5 km/h
Traction force	510 kN
Operating height	22685 mm
Operating width	4300 mm
