Product Details:
|
| Torque: | 150 KN.m | Max. Drilling Diameter: | 1300/1500mm |
|---|---|---|---|
| Max. Drilling Depth: | 42/52m | ||
| High Light: | Rotary Hydraulic Piling Rig Hole Bored,150 kN.m Rotary Hydraulic Piling Rig,1300mm Hydraulic Rotary Piling Rig |
||
| Technical Specification of KR90C Rotary Drilling Rig | ||
| Type | KR150A | |
| Torque | 150 kN.m | |
| Max. drilling diameter | 1300/1500mm | |
| Max. drilling depth | 42/52m | |
| Speed of rotation | 6~30 rpm | |
| Max. crowd pressure | 100 kN | |
| Max. crowd pull | 150 kN | |
| Main winch line pull | 110kN | |
| Main winch line speed | 78m/min | |
| Auxiliary winch line pull | 60 kN | |
| Auxiliary winch line speed | 60 m/min | |
| Stroke(crowd system) | 3800 mm | |
| Mast inclination(lateral) | ±3° | |
| Mast inclination(forward) | 5° | |
| Max. hydraulic pressure | 34.3 MPa | |
| Control hydraulic pressure | 3.9 MPa | |
| Travel speed | 2.8km/h | |
| Traction force | 229kN | |
| Operating height | 16175mm | |
| Operating width | 3390 mm | |
| Transport height | 3655 mm | |
| Transport width | 3390 mm | |
| Transport length | 14765 mm | |
| Overall weight | 40T | |
| Chassis | ||
| Type | Sinomach | |
| Engine | QSB7 | |
