Product Details:
|
| Max. Torque: | 60 KN.m | Max. Drilling Diameter: | 1000/1200 Mm |
|---|---|---|---|
| Max. Drilling Depth: | 28 M | Speed Of Rotation: | 6~30 Rpm |
| Max. Cylinder Stroke: | 3500 Mm | Excavator Size: | 24 T |
| High Light: | Kr90 Rotary Piling Drilling Rig,Rotary Drilling Piling Rig 1200mm,CE Rotary Drilling Piling Rig |
||
Technical Specification
| Type | KR90A |
| Torque | 90 KN.m |
| Max. diameter | 1200 mm |
| Max. drilling depth | 36 m |
| Speed of rotation | 6~30 rpm |
| Max. crowd pressure | 90 kN |
| Max. crowd pull | 120 kN |
| Main winch line pull | 80kN |
| Main winch line speed | 75 m/min |
| Auxiliary winch line pull | 50kN |
| Auxiliary winch line speed | 40 m/min |
| Stroke(crowd system) | 3500 mm |
| Mast inclination(lateral) | ±3° |
| Mast inclination(forward) | 4° |
| Max. operating pressure | 34.3 MPa |
| Pilot pressure | 3.9 MPa |
| Travel speed | 3 km/h |
| Traction force | 122 kN |
| Operating height | 12705 mm |
| Operating width | 2890mm |
| Transport height | 3465 mm |
| Transport width | 2770 mm |
| Transport length | 11385mm |
| Overall weight | 24 t |
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 7 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.
Q1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is one year or 2000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
