Product Details:
|
| Torque: | 50 KN.m | Max. Drilling Diameter: | 1200 Mm |
|---|---|---|---|
| Max. Drilling Depth: | 16 M | ||
| High Light: | Small rotary drilling rig Machine Portable,Kr50 rotary drilling rig,50kN.m Water Well drilling rig |
||
| Excavator Size | 7t-20t |
| Max. torque | 50 kN.m |
| Max. drilling diameter | 1200 mm |
| Max. drilling depth | 16 m |
| Main winch pull force | 70 kN |
| Main cylinder trip | 1100 mm |
| Auxiliary winch pull force | 65 kN |
| Main winch speed | 48 m/min |
| Mast inclination(Lateral) | ±6° |
| Mast inclination(Forward) | -30°~ +90° |
| Working speed | 7-40rpm |
| Min. radius of gyration | 2800mm |
| Max. pilot pressure | 31.5Mpa |
| Operating height | 8868mm |
| Operating width | 2600mm |
| Transport height | 2731mm |
| Transport width | 2600mm |
| Transport length | 10390mm |
| Transport weight | 6.1t |
| Remark | Restructuring big arm |
