Product Details:
|
Max. Torque: | 220kN.m | Max. Drilling Diameter: | 1800/2000mm |
---|---|---|---|
Weight: | 60t | ||
Highlight: | Horizontal directional drilling rig,KR220M drilling rig,Bore Pile Driver Hole Rig Machine |
CFA construction method | Max. diameter | 8000mm |
Max. drilling depth | 20m | |
Main winch line pull | 230 kN | |
Rotary drilling construction method | Max. Diameter | 1800/2000 mm |
Max. drilling depth | 51/64 m | |
Main winch line pull | 230 kN | |
Main winch line speed | 60 m/min | |
Working parameters | Max. torque | 220 kN.m |
Auxiliary winch line pull | 110 kN | |
Auxiliary winch line speed | 60 m/min | |
Mast inclination(lateral) | ±3° | |
Mast inclination(forward) | 5° | |
Max. operating pressure | 35 MPa | |
Pilot pressure | 3.9 MPa | |
Travel speed | 2.8 km/h | |
Traction force | 420 kN | |
Operating size | Operating height | 25955 mm(CFA) 21080mm(rotary drilling) |
Operating width | 3000 mm | |
Transport size | Transport height | 3256 mm |
Transport width | 3000 mm | |
Transport length | 15685 mm | |
Total weight | Overall weight | 60 t |
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.
FAQ
Q1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is 1 year or 2000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
Q2: What's your service ?
We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.
