Product Details:
|
| Max. Torque: | 165 KN.M | Max. Drilling Diameter: | 1500 Mm |
|---|---|---|---|
| Max. Drilling Depth: | 58/46m | Speed Of Rotation: | 7~28 Rpm |
| Max. Crowd Pressure: | 155 KN | Main Winch Line Speed: | 80 M/min |
| Stroke(crowd System): | 4200 Mm | Operating Height: | 19152 Mm |
| Operating Width: | 4100 Mm | Overall Weight: | 49 T |
| Engine Model: | CAT C7.1 159KW | Rated Power: | 159/1800rpm |
| Displacement: | 7.01L | ||
| High Light: | Auger Rotary Drilling Piling Rig Machine,70m/Min Drilling Piling Rig Machine,Auxiliary Winch Line Piling Rig Machine |
||
Technical Specificatio
| Type | KR165C |
| Torque | 165 KN.m |
| Max. diameter | 1500 mm |
| Max. drilling depth | 46 m |
| Speed of rotation | 7~28 rpm |
| Max. crowd pressure | 155 kN |
| Max. crowd pull | 160 kN |
| Main winch line pull | 160 kN |
| Main winch line speed | 80m/min |
| Auxiliary winch line pull | 60 kN |
| Auxiliary winch line speed | 70m/min |
| Stroke(crowd system) | 4200mm |
| Mast inclination(lateral) | ±3° |
| Mast inclination(forward) | 5° |
| Max. operating pressure | 35 MPa |
| Pilot pressure | 4 MPa |
| Track shoe width | 700 mm |
| Operating height | 19152 mm |
| Operating width | 4100mm |
| Transport height | 3321 mm |
| Transport width | 3100 mm |
| Overall weight | 49 t |
1. Undercarriage-----Reliable & Mature Excavator Supplier for Choice
Type: New & Used
Brand: CAT, JCM, SINOMACH, and other
2. Hydraulic Parts-----World Famous Brands
Gearbox Reducer: Imported REXROTH
Main Pump & Valve: Imported KAWASAKI (Japan)
Hose: Imported
3. Structure Parts-----Professional Structure Parts Supplier for XCMG
Our Services
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 countries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.
FAQ
Q1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is one year or 2000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
Q2: What's your service ?
We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.
How to Contact Us?
Send your Inquiry Details in the Below, Click "Send" Now!
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 7 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.
