Product Details:
|
| Product Name: | Electric Scissor Lift Table | Video Factory Inspection: | Provided |
|---|---|---|---|
| Mechanical Test Report: | Provided | Marketing Type: | Hot Product 2019 |
| Accessories: | Hopper | Diameter: | 1.58*0.74*1.1m |
| High Light: | Mobile Mechanism Hydraulic Electric Scissor Lifting,Hydraulic Electric Scissor Lifting With Guardrail,Hydraulic Electric Scissor Lifting Table |
||
| Model | TS6 |
| Size | Dimension |
| (A)Max Working Height | 7.8m |
| (B)Max Platform Height | 5.8m |
| (C)Platform Height-Stowed | 1m |
| Platform-Length | 1.58m |
| -Length extended | 2.48m |
| Platform Extended | 0.9m |
| (D)Platform Width-outside | 0.74m |
| Rail Height | 1.1m |
| Toe-guard Height | 0.13m |
| (E)Height-Stowed:(rail unfolded) | 2.1m |
| (rail folded) | 1.75m |
| (F)Length-Stowed | 1.78m |
| Length-extended | 2.66m |
| (G)Width | 0.81m |
| (H)Wheelbase | 1.3m |
|
(I)Ground Clearance (Pothole protection lay down) |
2cm |
| (J)Ground Clearance | 7cm |
Our Services
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
FAQ
What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is one year or 2000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
