Electric Core Drill Piling Rig Machine 15KN Crawler Mounted For Blasting Hole

Electric Core Drill Piling Rig Machine 15KN Crawler Mounted For Blasting Hole
Electric Core Drill Piling Rig Machine 15KN Crawler Mounted For Blasting Hole

Large Image :  Electric Core Drill Piling Rig Machine 15KN Crawler Mounted For Blasting Hole

Product Details:
Place of Origin: Jiangsu, China
Brand Name: TYSIM
Certification: ISO9001:2008
Model Number: GXYL-1
Payment & Shipping Terms:
Minimum Order Quantity: 1Set/Sets
Price: Negotiation
Packaging Details: In 40′container with drilling tools
Delivery Time: One month
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: five set per month
Detailed Product Description
Place Of Origin: Jiangsu, China (Mainland) Type: Anchor Drilling Rig
Color: Can Be Custom-made Brand Name: Tysim
Name: Electric Crawler Mounted Drill Rig For Blasting Engineering Hole Application: Asphalt Or Concrete Surface,Building
High Light:

Core Drill Piling Rig Machine

,

15KN Crawler Mounted Piling Rig Machine

,

Piling Rig Machine Electric

Electric Core Drill Rig / Crawler Mounted Drill Rig For Blasting Engineering Hole





Description:



1. GXYL-1 is a spindle type drill. It can be used in engineering geological exploration, survey and exploration of solid mineral deposit, blasting engineering hole, inspecting hole of various concrete stucture, etc.

2. According to various layer, it can be drilling with diamond bit, hard alloy bit, auger bit, etc.

3. The drilling rig has various chassis mode like skid mounted, crawler mounted.

4. The drill is convenient for maintenance and repair for simple structure and reasonable layout.

5. Opening the clinostat, it is easy to lift and loose the drill.



Applications:



1. Engineering geological exploration.

2. Survey and exploration of solid mineral deposit.

3. Blasting engineering hole.

4. Inspecting hole of various concrete stucture.



Specifications:



Hole depth 50m Rod dia 150mm
Hole depth 150m Rod dia 76mm

Hole angle(°)

360°
Spindle speed Forward speed:61;163;338;654rpm
Reverse speed:45rpm
Stroke of spindle 500mm
Max .lifting capacity 25KN
Max .feeding capacity 20KN

Max .distance from the spindle lower to the earth surface

600mm
Hoist

Max .lifting capacity

(single line):

15KN
Lifting speed: 0.2;0.52;1.05;2.06m/s
Power Electric motor: 11kw,2200rpm
Diesel engine S1100 or S1100M
Weight 500kg
Dimensions (L×W×H) 1450×970×1280mm







Bore pile drilling rigs Pilling Rotary rig Used drilling machine


1. The drill rig can drill up 23m , spiral drill rod with high effeciency working.
2. It has high drilling efficiency ,and After construction, It can quickly move to next worksite . flexible, convenient and efficient, 3.It is a national high-speed rail construction-specific piling machinery equipment.
