Low Headroom 125 KN.M Rotary Piling Rig Portable Piling Machine Diamegter 1300mm

Low Headroom 125 KN.M Rotary Piling Rig Portable Piling Machine Diamegter 1300mm
Low Headroom 125 KN.M Rotary Piling Rig Portable Piling Machine Diamegter 1300mm Low Headroom 125 KN.M Rotary Piling Rig Portable Piling Machine Diamegter 1300mm

Large Image :  Low Headroom 125 KN.M Rotary Piling Rig Portable Piling Machine Diamegter 1300mm

Product Details:
Place of Origin: Jiangsu, China
Brand Name: TYSIM
Certification: CE ISO9001
Model Number: KR125ES
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Method One: Nude packing and overall transport by sea with roll-on-roll-off ship. Method Two: Flat rack container
Delivery Time: 45 days after receiving the payment
Payment Terms: L/C, T/T, D/A
Supply Ability: 30 sets per year
Detailed Product Description
Torque: 125 KN.m Max. Diameter: 1300 Mm
Max. Drilling Depth: 20m Mast Inclination(forward):
Transport Height: 3500 Mm Transport Width: 2990 Mm
Transport Length: 13960 Mm Overall Weight: 35 T
High Light:

Low Headroom Piling Rig

,

portable piling machine

,

Diameter 1300mm Rotary Piling Rig

Technical Specification



Technical specification of KR125ES rotary drilling rig (Low headroom)

CFA construction method





Max. diameter 700mm
Max. drilling depth 15m
Main winch line pull 240 kN

Rotary drilling construction method









Max. Diameter 1300 mm
Max. drilling depth 20m
Main winch line pull 120 kN
Main winch line speed 78 m/min

Working parameters

















Max. torque 125 kN.m
Auxiliary winch line pull 60 kN
Auxiliary winch line speed 60 m/min
Mast inclination(lateral) ±3°
Mast inclination(forward)
Max. operating pressure 34.3 MPa
Pilot pressure 3.9 MPa
Travel speed 2.8 km/h
Traction force 204 kN

Operating size



Operating height 8000mm(rotary drilling)
Operating width 2990 mm

Transport size





Transport height 3500 mm
Transport width 2990 mm
Transport length 13960 mm
Total weight Overall weight 35 t



Product Details



1. Undercarriage-----Reliable & Mature Excavator Supplier for Choice

Type: New



Low Headroom 125 KN.M Rotary Piling Rig Portable Piling Machine Diamegter 1300mm 0



2. Hydraulic Parts-----World Famous Brands

Gearbox Reducer: Imported REXROTH

Main Pump & Valve: Imported KAWASAKI (Japan)

Hose: Imported

Low Headroom 125 KN.M Rotary Piling Rig Portable Piling Machine Diamegter 1300mm 1



3. Structure Parts-----Professional Structure Parts Supplier for XCMG

Low Headroom 125 KN.M Rotary Piling Rig Portable Piling Machine Diamegter 1300mm 2





KR size small and medium-sized rotary drilling rig in many fields of metro,viaduct,houses win the praise of all the customers for the construction result,it will be the low cost and high efficient pile working equipments in operation field of our country’s new urbanizational construction. With the goal “be the reliable pile working proficient,fabricate the trade leading outstanding productions”,we recruit excellent talents constantly,create cause terrace for the win-win situation between staffs and company.We stick to the core concept“concentration,creative,value”concentrate on research and development in the pile basical construction field,rely on the working style of“pay attentions to details,keep improving,against the tardiness, finish daily duty”make great efforts to realize the vision of “become the pacemaker of small and medium-sized pile working machinery”.

packing&shipping



Low Headroom 125 KN.M Rotary Piling Rig Portable Piling Machine Diamegter 1300mm 3





Why Choose Us?



1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.

2. Supply professional customized service to meet all your requirements.

3. Our rotary drilling rigs have been sold to more than 7 counstries, such as Russia, Australia, Thailand, Zambia and others.

4. Competitive price.



FAQ


Q1: What is the Warranty of the Rotary Drilling Rig?

The warranty period for new machine is one year or 2000 working hours, whichever comes first will be applied.

Please contact with us for detailed Warranty Regulation.
