Excavator Water Well Drill Foundation Drilling Rock Auger KR150A 1300mm

Excavator Water Well Drill Foundation Drilling Rock Auger KR150A 1300mm
Excavator Water Well Drill Foundation Drilling Rock Auger KR150A 1300mm Excavator Water Well Drill Foundation Drilling Rock Auger KR150A 1300mm Excavator Water Well Drill Foundation Drilling Rock Auger KR150A 1300mm

Large Image :  Excavator Water Well Drill Foundation Drilling Rock Auger KR150A 1300mm

Product Details:
Place of Origin: Jiangsu, China
Brand Name: TYSIM
Certification: CE,ISO9001
Model Number: KR150A
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Method One: Nude packing and overall transport by sea with roll-on-roll-off ship.
Delivery Time: 30 working days after receiving the advance payment
Payment Terms: L/C, T/T
Supply Ability: 5 set per month
Detailed Product Description
Max. Torque: 150 KN.m Max. Drilling Diameter: 1300/1500mm
Max. Drilling Depth: 42/52m Speed Of Rotation: 6~30 Rpm
Max. Crowd Pressure: 100 KN Main Winch Line Speed: 78m/min
Stroke(crowd System): 3800 Mm Operating Height: 16175mm
Operating Width: 3390 Mm Overall Weight: 40t
Main Winch Line Pull: 110kN Travel Speed: 2.8km/h
Traction Force: 229kN
High Light:

Excavator Water Well Auger Drill

,

Foundation Drilling Rock Auger

,

1300mm Hydraulic Piling Rig

Technical Specification

Technical Specification of KR90C Rotary Drilling Rig
Type KR150A
Torque 150 kN.m
Max. drilling diameter 1300/1500mm
Max. drilling depth 42/52m
Speed of rotation 6~30 rpm
Max. crowd pressure 100 kN
Max. crowd pull 150 kN
Main winch line pull 110kN
Main winch line speed 78m/min
Auxiliary winch line pull 60 kN
Auxiliary winch line speed 60 m/min
Stroke(crowd system) 3800 mm
Mast inclination(lateral) ±3°
Mast inclination(forward)
Max. hydraulic pressure 34.3 MPa
Control hydraulic pressure 3.9 MPa
Travel speed 2.8km/h
Traction force 229kN
Operating height 16175mm
Operating width 3390 mm
Transport height 3655 mm
Transport width 3390 mm
Transport length 14765 mm
Overall weight 40T
Chassis
Type Sinomach
Engine QSB7




1. Undercarriage-----Reliable & Mature Excavator Supplier for Choice

Type: New & Used

Brand: CAT, JCM, SINOMACH, SANY, XCMG and other



2. Hydraulic Parts-----World Famous Brands

Gearbox Reducer: Imported REXROTH

Main Pump & Valve: Imported KAWASAKI (Japan)

Hose: Imported



3. Structure Parts-----Professional Structure Parts Supplier for XCMG



Excavator Water Well Drill Foundation Drilling Rock Auger KR150A 1300mm 0



Excavator Water Well Drill Foundation Drilling Rock Auger KR150A 1300mm 1

Certificates
Excavator Water Well Drill Foundation Drilling Rock Auger KR150A 1300mm 2
Excavator Water Well Drill Foundation Drilling Rock Auger KR150A 1300mm 3
Excavator Water Well Drill Foundation Drilling Rock Auger KR150A 1300mm 4

Our Services
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 countries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.

FAQ
Q1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is one year or 2000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
Q2: What's your service ?
We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.
