40T Hydraulic Drilling Piling Rig Machine Tysim KR150A 52 / 42m Diameter 1300 / 1500mm

40T Hydraulic Drilling Piling Rig Machine Tysim KR150A 52 / 42m Diameter 1300 / 1500mm
40T Hydraulic Drilling Piling Rig Machine Tysim KR150A 52 / 42m Diameter 1300 / 1500mm
40T Hydraulic Drilling Piling Rig Machine Tysim KR150A 52 / 42m Diameter 1300 / 1500mm 40T Hydraulic Drilling Piling Rig Machine Tysim KR150A 52 / 42m Diameter 1300 / 1500mm 40T Hydraulic Drilling Piling Rig Machine Tysim KR150A 52 / 42m Diameter 1300 / 1500mm 40T Hydraulic Drilling Piling Rig Machine Tysim KR150A 52 / 42m Diameter 1300 / 1500mm 40T Hydraulic Drilling Piling Rig Machine Tysim KR150A 52 / 42m Diameter 1300 / 1500mm

Large Image :  40T Hydraulic Drilling Piling Rig Machine Tysim KR150A 52 / 42m Diameter 1300 / 1500mm

Product Details:
Place of Origin: jiangsu,China
Brand Name: Tysim
Certification: CE/ISO900A
Model Number: KR150A
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Nude packing and overall transport by sea with roll-on-roll-off ship; One Flat rack container.
Delivery Time: 45 working days after received your payment
Payment Terms: L/C, T/T
Supply Ability: 30 sets per month

40T Hydraulic Drilling Piling Rig Machine Tysim KR150A 52 / 42m Diameter 1300 / 1500mm

Description
Torque: 150kN.m Max. Drilling Diameter: 1300/1500 Mm
Max. Drilling Depth: 52/42 M
High Light:

Hydraulic Drilling Piling Rig Machine

,

1500mm Drilling Rig Machine

,

42m Piling Drilling Rig Machine



40T Hydraulic Drilling Piling Rig Machine Tysim KR150A 52 / 42m Diameter 1300 / 1500mm 0





​​

Type KR150A
Torque 150KN.m
Max. diameter 11500mm
Max. drilling depth 52 m
Speed of rotation 6~30 rpm
Max. crowd pressure 100 kN
Max. crowd pull 150 kN
Main winch line pull 110 kN
Main winch line speed 78 m/min
Auxiliary winch line pull 60 kN
Auxiliary winch line speed 60 m/min
Stroke(crowd system) 3800 mm
Mast inclination(lateral) ±3°
Mast inclination(forward)
Max. operating pressure 34.3 MPa
Pilot pressure 3.9 MPa
Travel speed 3 km/h
Traction force 229 kN
Operating height 16175m
Operating width 3390
Transport height 3655 mm
Transport width 3390 mm
Transport length 14765mm
Overall weight 40 t



​​





40T Hydraulic Drilling Piling Rig Machine Tysim KR150A 52 / 42m Diameter 1300 / 1500mm 13
40T Hydraulic Drilling Piling Rig Machine Tysim KR150A 52 / 42m Diameter 1300 / 1500mm 14



Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.

FAQ

Q1: What is the Warranty of the Rotary Drilling Rig?

The warranty period for new machine is 1 year or 2000 working hours, whichever comes first will be applied.

Please contact with us for detailed Warranty Regulation.

Q2: What's your service ?

We can offer professional technical support and good after-sale service to you.

Modification methods will be different according to different models and configurations of your owned excavators.

Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.

Before modifying, you need to confirm technical specification.
