Product Details:
|
| Torque: | 90kN.m | Max. Drilling Diameter: | 1200 Mm |
|---|---|---|---|
| Max. Drilling Depth: | 36 M | ||
| High Light: | hydraulic rotary pile rig machine,Hydraulic Piling Rig 1200Mm,30Rpm Hydraulic drilling Piling Rig |
||
| Type | KR90C |
| Torque | 90KN.m |
| Max. diameter | 1200 mm |
| Max. drilling depth | 32 m |
| Speed of rotation | 8~30 rpm |
| Max. crowd pressure | 90 kN |
| Max. crowd pull | 120 kN |
| Main winch line pull | 90 kN |
| Main winch line speed | 75 m/min |
| Auxiliary winch line pull | 35 kN |
| Auxiliary winch line speed | 40 m/min |
| Stroke(crowd system) | 3500 mm |
| Mast inclination(lateral) | ±3° |
| Mast inclination(forward) | 4° |
| Max. operating pressure | 35 MPa |
| Pilot pressure | 3.9 MPa |
| Travel speed | 2.8 km/h |
| Traction force | 156 kN |
| Operating height | 14550 mm |
| Operating width | 2600mm |
| Transport height | 3480 mm |
| Transport width | 2600 mm |
| Transport length | 13100mm |
| Overall weight | 28 t |
