Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm.

Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm.
Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm. Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm. Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm.

Large Image :  Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm.

Product Details:
Place of Origin: Jiangsu, China
Brand Name: TYSIM
Certification: CE,ISO9001
Model Number: KR220C
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Method One: Nude packing and overall transport by sea with roll-on-roll-off ship.
Delivery Time: 30 working days after receiving the advance payment
Payment Terms: L/C, T/T
Supply Ability: 5 set per month

Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm.

Description
Max. Torque: 220 KN.m Max. Drilling Diameter: 1800/2000 Mm
Max. Drilling Depth: 64/51 M Speed Of Rotation: 5~26 Rpm
Max. Crowd Pressure: 210kN Main Winch Line Speed: 60m/min
Stroke(crowd System): 5000mm Operating Height: 21082 Mm
Operating Width: 4300mm Overall Weight: 65 T
Auxiliary Winch Line Speed: 60m/min Mast Inclination(lateral): ±5°
Max. Operating Pressure: 35 MPa Pilot Pressure: 4 MPa
High Light:

Short Mast Rotary Drilling Rig

,

2000 Mm Rotary Drilling Rig

,

KR220C Hand Auger Drilling Rig

Technical Specification

Type KR220C
Torque 220 KN.m
Max. diameter 1800/2000 mm
Max. drilling depth 64/51 m
Speed of rotation 5~26 rpm
Max. crowd pressure 210kN
Max. crowd pull 2200 kN
Main winch line pull 230kN
Main winch line speed 60m/min
Auxiliary winch line pull 90kN
Auxiliary winch line speed 60m/min
Stroke(crowd system) 5000mm
Mast inclination(lateral) ±5°
Mast inclination(forward)
Max. operating pressure 35 MPa
Pilot pressure 4 MPa
Track shoe width 800 mm
Operating height 21082 mm
Operating width 4300mm
Transport height 3360mm
Transport width 3000mm
Overall weight 65 t



Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm. 0    Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm. 1

Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm. 2



1. Undercarriage-----Reliable & Mature Excavator Supplier for Choice

Type: New & Used

Brand: CAT, JCM, SINOMACH, SANY, XCMG and other



2. Hydraulic Parts-----World Famous Brands

Gearbox Reducer: Imported REXROTH

Main Pump & Valve: Imported KAWASAKI (Japan)

Hose: Imported



3. Structure Parts-----Professional Structure Parts Supplier for XCMG



Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm. 3



Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm. 4



Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm. 5

Certificates
Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm. 6
Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm. 7
Short Mast Rotary Drilling Rig Hand Auger Tools Rest Assured Safe KR220C 2000 Mm. 8

Our Services
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 countries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.

FAQ
Q1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is one year or 2000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
Q2: What's your service ?
We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.
